9RF0924P1H001

Active

Sanyo Denki America Inc.

FAN AXIAL 92X38MM 24VDC WIRE

Search across all available documentation for this part.

Active

Sanyo Denki America Inc.

FAN AXIAL 92X38MM 24VDC WIRE

Technical Specifications

Parameters and characteristics for this part

Specification	9RF0924P1H001

Air Flow	1.19 mł/min
Air Flow	42.4 CFM
Approval Agency	cURus, TUV
Bearing Type	Ball
Current Rating (Amps)	0.09 A
Fan Type	Tubeaxial
Features	Speed Sensor (Tach), PWM Control, Reversible Flow
Lifetime @ Temp.	40000 Hrs
Material - Blade	Plastic
Material - Frame	Plastic
Noise	39 dB(A)
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 °C
Operating Temperature [Min]	-20 C
Power (Watts)	2.2 W
Size / Dimension [diameter]	92 mm
Static Pressure	156.9 Pa
Static Pressure	0.63 in H2O
Termination	4 Wire Leads
Voltage - Rated	24 VDC
Width [y]	38 mm

Part	Static Pressure	Static Pressure	Current Rating (Amps)	Width [y]	Air Flow	Air Flow	Material - Blade	Power (Watts)	Material - Frame	Features	Approval Agency	Noise	Operating Temperature [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Lifetime @ Temp.	Voltage - Rated	Bearing Type	Termination	Size / Dimension [diameter]	Fan Type
Sanyo Denki America Inc. 9RF0924P1H001	156.9 Pa	0.63 in H2O	0.09 A	38 mm	1.19 mł/min	42.4 CFM	Plastic	2.2 W	Plastic	PWM Control Reversible Flow Speed Sensor (Tach)	cURus TUV	39 dB(A)	-20 °C	70 °C	-20 C	70 °C	40000 Hrs	24 VDC	Ball	4 Wire Leads	92 mm	Tubeaxial
