50105C
ActiveMurata Power Solutions Inc.
CHOKE, SURFACE MOUNT, 1 MH, 5000 SERIES, 700 MA, 9.3MM X 5.9MM X 4.4MM
Deep-Dive with AI
Search across all available documentation for this part.
50105C
ActiveMurata Power Solutions Inc.
CHOKE, SURFACE MOUNT, 1 MH, 5000 SERIES, 700 MA, 9.3MM X 5.9MM X 4.4MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 50105C |
|---|---|
| Current Rating (Max) [Max] | 700 mA |
| DC Resistance (DCR) (Max) [Max] | 300 mOhm |
| Filter Type | Power Line |
| Height (Max) | 4.65 mm |
| Height (Max) [Max] | 0.183 in |
| Inductance @ Frequency | 1 mH |
| Mounting Type | Surface Mount |
| Number of Lines | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4 J-Lead, Horizontal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
50 Series
The 50105C is a 700mA surface-mount Common Mode Choke designed to attenuate up to 100MHz common mode noise where line filtering is required. Backward compatible with Sn/Pb soldering systems and the pin is of pure tin dip finish.
