MDR-134-1

Active

TE Connectivity Aerospace, Defense and Marine

RELAY GEN PURPOSE 8PDT 10A 115V

Search across all available documentation for this part.

Active

TE Connectivity Aerospace, Defense and Marine

RELAY GEN PURPOSE 8PDT 10A 115V

Technical Specifications

Parameters and characteristics for this part

Part	Coil Current	Contact Material	Coil Type	Termination Style	Operate Time	Contact Rating (Current)	Coil Voltage	Relay Type	Mounting Type	Operating Temperature [Max]	Coil Resistance	Contact Form	Release Time
TE Connectivity Aerospace, Defense and Marine MDR-134-1	215 mA	Silver Cadmium Oxide (AgCdO)	Non Latching	Screw Terminal	16 ms	10 A	115 VAC	General Purpose	Chassis Mount	65 °C	534.8 Ohms	8PDT (8 Form C)
TE Connectivity Aerospace, Defense and Marine MDR-163-1	230 mA		Non Latching	Screw Terminal	12 ms	10 A	115 VAC	General Purpose	Chassis Mount	65 °C	62 Ohms		18 ms
TE Connectivity Aerospace, Defense and Marine MDR-131-1	215 mA		Non Latching	Screw Terminal	12 ms	10 A	115 VAC	General Purpose	Chassis Mount	65 °C	66 Ohms	4PDT (4 Form C)	18 ms

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 2715.36

General part information

General Purpose Relay 8PDT (8 Form C) 115VAC Coil Chassis Mount

Technical documentation and resources
