Q-2C01400052.5M
ActiveAmphenol Custom Cable
CBL ASSY MCX-NTYPE JACK-PLG 8.2'
Deep-Dive with AI
Search across all available documentation for this part.
Q-2C01400052.5M
ActiveAmphenol Custom Cable
CBL ASSY MCX-NTYPE JACK-PLG 8.2'
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | Q-2C01400052.5M |
|---|---|
| 1st Connector | MCX Jack |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Contact Gender | Female |
| 2nd Connector | N-Type Plug, Right Angle |
| 2nd Connector Mounting Type | Free Hanging (In-Line) |
| 2nd Contact Gender | Male |
| Cable Type | RG-316 |
| Color | Copper |
| Features | Shielded |
| Frequency - Max [Max] | 6000 MHz |
| Length | 8.2 ' |
| Length | 98.4 in |
| Length | 2.5 m |
| Overall Impedance | 50 Ohms |
| Style | MCX to N-Type |
Q-2C0140 Series
| Part | Overall Impedance | Style | 1st Contact Gender | 1st Connector Mounting Type | 2nd Connector Mounting Type | 2nd Contact Gender | Color | 1st Connector | Cable Type | Frequency - Max [Max] | Length | Length | Length | Features | 2nd Connector | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Black | MCX Jack | RG-174 | 6000 MHz | 84 in | 2.1 m | 7 ft | Shielded | N-Type Plug Right Angle | ||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Black | MCX Jack | RG-174 | 6000 MHz | 12 " | 304.8 mm | Shielded | N-Type Plug Right Angle | |||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Black | MCX Jack | RG-174 | 6000 MHz | 24 " | 609.6 mm | Shielded | N-Type Plug Right Angle | |||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Black | MCX Jack | RG-174 | 6000 MHz | Shielded | N-Type Plug Right Angle | 457.2 mm | 457.2 mm | |||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Copper | MCX Jack | RG-316 | 6000 MHz | 3 in | 76.2 mm | Shielded | N-Type Plug Right Angle | |||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Black | MCX Jack | RG-174 | 6000 MHz | 59.1 in | 1.5 m | 4.9 ft | Shielded | N-Type Plug Right Angle | ||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Copper | MCX Jack | RG-316 | 6000 MHz | 98.4 in | 2.5 m | 8.2 ' | Shielded | N-Type Plug Right Angle | ||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Copper | MCX Jack | RG-316 | 6000 MHz | 108 in | 2.7 m | 9 ft | Shielded | N-Type Plug Right Angle | ||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Black | MCX Jack | RG-174 | 6000 MHz | 19.69 " | 50 cm | Shielded | N-Type Plug Right Angle | |||
Amphenol Custom Cable | 50 Ohms | MCX to N-Type | Female | Free Hanging (In-Line) | Free Hanging (In-Line) | Male | Black | MCX Jack | RG-174 | 6000 MHz | 108 in | 2.7 m | 9 ft | Shielded | N-Type Plug Right Angle |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 103.48 | |
| 25 | $ 96.44 | |||
| 50 | $ 89.40 | |||
| 100 | $ 83.37 | |||
| 250 | $ 78.34 | |||
Description
General part information
Q-2C0140 Series
Cable Assembly Coaxial MCX to N-Type RG-316 98.4" (2.5m) 8.2'
