1702199

Active

Phoenix Contact

FIXED TERMINAL BLOCKS MKDSN 2.5/ 6-BK

Search across all available documentation for this part.

Active

Phoenix Contact

FIXED TERMINAL BLOCKS MKDSN 2.5/ 6-BK

Technical Specifications

Parameters and characteristics for this part

Fixed Terminal Blocks 4P 5.08mm 90DEG

Part	Mating Orientation	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Screw Thread	Wire Gauge [Max]	Wire Gauge [Min]	Pitch [x]	Pitch [x]	Positions Per Level	Mounting Type	Color	Wire Termination	Number of Levels	Voltage	Current	Features	Housing Material
Phoenix Contact 1702199	Horizontal with Board	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	M3	30 AWG	12 AWG	5 mm	0.197 in	6	Through Hole	Black	Screw - Rising Cage Clamp	1	300 V	20 A
Phoenix Contact 1888700	Horizontal with Board	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	M3	30 AWG	12 AWG	5.08 mm	0.2 in	4	Through Hole	Green	Screw - Rising Cage Clamp	1	300 V	20 A	Interlocking (Side)	Polyamide (PA) Nylon

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fixed Terminal Blocks 4P 5.08mm 90DEG

Technical documentation and resources

No documents available
