1701A 8773000

Obsolete

Belden Inc.

CAT5E+ 4PRB U/UTP CMP REEL

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

1701A 8773000

Obsolete

Belden Inc.

CAT5E+ 4PRB U/UTP CMP REEL

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	1701A 8773000

Cable Type	Multi-Pair, Cat5e
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Bare
Conductor Strand	Solid
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	0.195 in
Jacket (Insulation) Diameter [diameter]	4.95 mm
Jacket (Insulation) Material	Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum
Jacket Color	Natural
Length	914.4 m
Length	3000 ft
Number of Conductors	8
Ratings	UL Style CMP
Usage	Network
Voltage	300 V
Wire Gauge	24 AWG

1701A Series

Part	Jacket Color	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Cable Type	Usage	Conductor Strand	Features	Voltage	Conductor Material	Length	Length	Wire Gauge	Number of Conductors	Conductor Insulation	Jacket (Insulation) Material	Ratings
Belden Inc. 1701A B021000	Purple	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	1000 ft	304.8 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A 008U1000	Gray	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	1000 ft	304.8 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A 8773000	Natural	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	3000 ft	914.4 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A D153000	Blue	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	3000 ft	914.4 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A 877U1000	Natural	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	1000 ft	304.8 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A 004U1000	Yellow	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	1000 ft	304.8 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A 0021000	Red	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	1000 ft	304.8 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A 0031000	Orange	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	1000 ft	304.8 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A 0051000	Green	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	1000 ft	304.8 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP
Belden Inc. 1701A 8771000	Natural	0.195 in	4.95 mm	Multi-Pair Cat5e	Network	Solid	Rip Cord	300 V	Copper Bare	1000 ft	304.8 m	24 AWG	8	Fluorinated Ethylene-Propylene (FEP)	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	UL Style CMP

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

1701A Series

8 (4 Pair) Conductor Multi-Pair, Cat5e Cable Natural 24 AWG 3000' (914.4m)

Documents

Technical documentation and resources
