TCJT336M006R0150E

Active

Kyocera AVX

CAP TANT POLY 33UF 6.3V 1210

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsPolymer, Tantalum, Niobium Oxide Catalog Datasheet

TCJT336M006R0150E

Active

Kyocera AVX

CAP TANT POLY 33UF 6.3V 1210

Deep-Dive with AI

DocumentsPolymer, Tantalum, Niobium Oxide Catalog Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TCJT336M006R0150E

Capacitance	33 ÁF
ESR (Equivalent Series Resistance)	150 mOhm
Features	General Purpose
Height - Seated (Max) [Max]	1.2 mm
Height - Seated (Max) [Max]	0.047 in
Lifetime @ Temp.	2000 Hrs
Manufacturer Size Code	T
Mounting Type	Surface Mount
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Package / Case	1210 (3528 Metric)
Size / Dimension [x]	0.138 "
Size / Dimension [x]	3.5 mm
Size / Dimension [y]	0.11 in
Size / Dimension [y]	2.8 mm
Tolerance	20 %
Type	Molded
Voltage - Rated	6.3 V

TCJT Series

Part	Features	Mounting Type	Voltage - Rated	Lifetime @ Temp.	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Tolerance	ESR (Equivalent Series Resistance)	Package / Case	Type	Capacitance	Operating Temperature [Max]	Operating Temperature [Min]	Manufacturer Size Code
Kyocera AVX TCJT226M010R0150	General Purpose	Surface Mount	10 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	150 mOhm	1210 (3528 Metric)	Molded	22 µF	105 ░C	-55 °C	T
Kyocera AVX TCJT107M006R0200	General Purpose	Surface Mount	6.3 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	200 mOhm	1210 (3528 Metric)	Molded	100 µF	105 ░C	-55 °C	T
Kyocera AVX TCJT686M006S0200	General Purpose	Surface Mount	6.3 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	200 mOhm	1210 (3528 Metric)	Molded	68 µF	105 ░C	-55 °C	T
Kyocera AVX TCJT106M016R0150E	General Purpose	Surface Mount	16 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	150 mOhm	1210 (3528 Metric)	Molded	10 µF	125 °C	-55 °C	T
Kyocera AVX TCJT476M006R0120	General Purpose	Surface Mount	6.3 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	120 mOhm	1210 (3528 Metric)	Molded	47 µF	105 ░C	-55 °C	T
Kyocera AVX TCJT107M004R0070	General Purpose	Surface Mount	4 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	70 mOhm	1210 (3528 Metric)	Molded	100 µF	105 ░C	-55 °C	T
Kyocera AVX TCJT685M025R0150E	General Purpose	Surface Mount	25 VDC	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	150 mOhm	1210 (3528 Metric)	Molded	6.8 ÁF	105 ░C	-55 °C	T
Kyocera AVX TCJT107M006S0200	General Purpose	Surface Mount	6.3 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	200 mOhm	1210 (3528 Metric)	Molded	100 µF	105 ░C	-55 °C	T
Kyocera AVX TCJT476M006R0080	General Purpose	Surface Mount	6.3 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	80 mOhm	1210 (3528 Metric)	Molded	47 µF	105 ░C	-55 °C	T
Kyocera AVX TCJT336M006R0150E	General Purpose	Surface Mount	6.3 V	2000 Hrs	0.11 in	2.8 mm	0.138 "	3.5 mm	1.2 mm	0.047 in	20 %	150 mOhm	1210 (3528 Metric)	Molded	33 ÁF	105 ░C	-55 °C	T

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	2500	$ 0.59

Description

General part information

TCJT Series

33 µF Molded Tantalum Polymer Capacitor 6.3 V 1210 (3528 Metric) 150mOhm @ 100kHz

Documents

Technical documentation and resources

Polymer, Tantalum, Niobium Oxide Catalog

Datasheet
