431113-09-0

Active

Curtis Industries

CONN BARRIER STRIP 9CIRC 0.438"

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Terminal Blocks Catalog

431113-09-0

Active

Curtis Industries

CONN BARRIER STRIP 9CIRC 0.438"

Deep-Dive with AI

DocumentsDatasheet Terminal Blocks Catalog

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	431113-09-0

Barrier Type	2 Wall (Dual)
Bottom Termination	PC Pin
Current Rating (Amps)	20 A
Material - Insulation	Polypropylene (PP)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Rows	1
Number of Wire Entries	9
Operating Temperature	105 C
Pitch [x]	11.12 mm
Pitch [x]	0.438 in
Terminal Block Type	Barrier Block
Terminal Screw Material	Steel, Stainless
Top Termination	Screws
Voltage Rating	600 V
Wire Gauge [Max]	22 AWG
Wire Gauge [Min]	12 AWG

431113 Series

Part	Terminal Screw Material	Terminal Block Type	Bottom Termination	Top Termination	Mounting Type	Material - Insulation	Pitch [x]	Pitch [x]	Material Flammability Rating	Barrier Type	Wire Gauge [Min]	Wire Gauge [Max]	Number of Circuits	Number of Wire Entries	Voltage Rating	Operating Temperature	Current Rating (Amps)	Number of Rows	Number of Wire Entries [custom]	Number of Circuits [custom]
Curtis Industries 431113-19-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG	19	19	600 V	105 C	20 A	1
Curtis Industries 431113-07-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG	7	7	600 V	105 C	20 A	1
Curtis Industries 431113-24-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG	24		600 V	105 C	20 A	1
Curtis Industries 431113-09-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG		9	600 V	105 C	20 A	1
Curtis Industries 431113-10-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG	10	10	600 V	105 C	20 A	1
Curtis Industries 431113-06-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG	6	6	600 V	105 C	20 A	1
Curtis Industries 431113-04-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG	4	4	600 V	105 C	20 A	1
Curtis Industries 431113-14-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG	14	14	600 V	105 C	20 A	1
Curtis Industries 431113-22-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG	22		600 V	105 C	20 A	1	22
Curtis Industries 431113-08-0	Stainless Steel	Barrier Block	PC Pin	Screws	Through Hole	Polypropylene (PP)	11.12 mm	0.438 in	UL94 V-0	2 Wall (Dual)	12 AWG	22 AWG		8	600 V	105 C	20 A	1		8

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 7.80
		10	$ 6.15
		25	$ 5.85
		50	$ 5.31
		100	$ 5.10
		250	$ 4.50
		500	$ 4.20
		1000	$ 3.90

Description

General part information

431113 Series

9 Circuit 0.438" (11.12mm) Barrier Block Connector Screws
