12038GE-12N-YA-F0
ActiveNMB TECHNOLOGIES
DC AXIAL FAN, 12 V, CIRCULAR, 120 MM, 38 MM, BALL BEARING, 45.2 CFM
Deep-Dive with AI
Search across all available documentation for this part.
12038GE-12N-YA-F0
ActiveNMB TECHNOLOGIES
DC AXIAL FAN, 12 V, CIRCULAR, 120 MM, 38 MM, BALL BEARING, 45.2 CFM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 12038GE-12N-YA-F0 |
|---|---|
| Air Flow | 1.26 mł/min |
| Air Flow | 45 CFM |
| Bearing Type | Ball |
| Current Rating (Amps) | 0.24 A |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Lifetime @ Temp. | 70000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Noise | 38 dB(A) |
| Operating Temperature [Max] | 40 °C |
| Operating Temperature [Max] | 40 °C |
| Operating Temperature [Min] | -40 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 2.88 W |
| RPM | 1950 RPM |
| Size / Dimension [diameter] | 120 mm |
| Static Pressure | 0.31 in H2O |
| Static Pressure | 77.2 Pa |
| Termination | 2 Wire Leads |
| Voltage - Rated | 12 VDC |
| Voltage Range [Max] | 13.2 VDC |
| Voltage Range [Min] | 7 V |
| Width [y] | 38 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
12038GE Series
Fan Tubeaxial 12VDC Round - 120mm Dia Ball 45.0 CFM (1.26mł/min) 2 Wire Leads
