ACFM-7101-TR1G

Obsolete

Broadcom Limited

RF QUINTPLEX 859MHZ/1.92GHZ 6SMD

Search across all available documentation for this part.

Obsolete

Broadcom Limited

RF QUINTPLEX 859MHZ/1.92GHZ 6SMD

Technical Specifications

Parameters and characteristics for this part

Specification	ACFM-7101-TR1G

Frequency Bands (Low / High) [Max] [custom]	894 MHz
Frequency Bands (Low / High) [Max] [custom]	1.99 GHz
Frequency Bands (Low / High) [Min] [custom]	824 MHz
Frequency Bands (Low / High) [Min] [custom]	1.85 GHz
High Band Attenuation (min / max dB) [Max]	-
High Band Attenuation (min / max dB) [Min]	30 dB
Low Band Attenuation (min / max dB) [Max]	-
Low Band Attenuation (min / max dB) [Min]	55 dB
Mounting Type	Surface Mount
Package / Case	6-SMD, No Lead
Return Loss (Low Band / High Band)	12 dB
Type	Quintplexer

Part	Mounting Type	Frequency Bands (Low / High) [Min] [custom]	Frequency Bands (Low / High) [Min] [custom]	Frequency Bands (Low / High) [Max] [custom]	Frequency Bands (Low / High) [Max] [custom]	High Band Attenuation (min / max dB) [Min]	High Band Attenuation (min / max dB) [Max]	Low Band Attenuation (min / max dB) [Max]	Low Band Attenuation (min / max dB) [Min]	Return Loss (Low Band / High Band)	Type	Package / Case
Broadcom Limited ACFM-7101-TR1G	Surface Mount	824 MHz	1.85 GHz	894 MHz	1.99 GHz	30 dB	-	-	55 dB	12 dB	Quintplexer	6-SMD No Lead
