Technical Specifications
Parameters and characteristics for this part
| Specification | SI1004-C-GM |
|---|---|
| Current - Receiving | 18.5 mA |
| Current - Transmitting [Max] | 30 mA |
| Current - Transmitting [Min] | 17 mA |
| Data Rate (Max) | 256 kbps |
| Frequency [Max] | 960 MHz |
| Frequency [Min] | 240 MHz |
| GPIO | 19 |
| Memory Size [custom] | 64 kB |
| Memory Size [custom] | 4.35 kB |
| Modulation | GFSK, OOK, FSK |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 42-WFQFN Exposed Pad |
| Power - Output | 13 dBm |
| Protocol | EZRadioPro |
| RF Family/Standard | General ISM < 1GHz |
| Sensitivity | -121 dBm |
| Serial Interfaces | UART, I2C, SPI |
| Supplier Device Package | 42-QFN |
| Supplier Device Package [x] | 5 |
| Supplier Device Package [y] | 7 |
| Type | TxRx + MCU |
| Voltage - Supply [Max] | 3.6 V |
| Voltage - Supply [Min] | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
SI1004 Series
IC RF TxRx + MCU General ISM < 1GHz EZRadioPro 240MHz ~ 960MHz 42-WFQFN Exposed Pad
