KIT40263G

Active

Amphenol Socapex

CONN MOD JACK 8P8C SHIELDED

Search across all available documentation for this part.

Active

Amphenol Socapex

CONN MOD JACK 8P8C SHIELDED

Technical Specifications

Parameters and characteristics for this part

Specification	KIT40263G

Connector Type	Jack with USB A
Features	Circular Threaded Coupling, Heat Shrink Tubing
LED Color	Does Not Contain LED
Mounting Type	Bulkhead, Panel Mount
Number of Ports	1
Number of Rows	1
Orientation	Straight
Shielding	Shielded
Tab Direction	User Selectable
Termination	Solder

Part	Connector Type	Mounting Type	Shielding	LED Color	Termination	Number of Rows	Orientation	Number of Ports	Features	Tab Direction	Orientation	Number of Positions/Contacts	Length	Length	Color	Configuration
Amphenol Socapex KIT40263G	Jack with USB A	Bulkhead Panel Mount	Shielded	Does Not Contain LED	Solder	1	Straight	1	Circular Threaded Coupling Heat Shrink Tubing	User Selectable
Amphenol Socapex KIT40035	Jack	Panel Mount Square Flange	Shielded	Does Not Contain LED	PC Board Solder	1		1	Circular Threaded Coupling	Side	90 °	8p8c (RJ45 Ethernet)
Amphenol Socapex KIT40739			Shielded						Industrial Environments - IP68				1070 mm	42 "	Black	A Female to Cable Round (Circular Coupling)
Amphenol Socapex KIT40792	Jack	Bulkhead Panel Mount	Shielded	Does Not Contain LED	Solder	1		1	Circular Threaded Coupling Heat Shrink Tubing	User Selectable	90 °	8p8c (RJ45 Ethernet)
Amphenol Socapex KIT40263	Jack with USB A	Bulkhead Panel Mount	Shielded	Does Not Contain LED	Solder	1	Straight	1	Circular Threaded Coupling Heat Shrink Tubing	User Selectable
Amphenol Socapex KIT40771	Jack	Bulkhead Panel Mount	Shielded	Does Not Contain LED	Solder	1		1	Circular Threaded Coupling Heat Shrink Tubing	User Selectable	90 °	8p8c (RJ45 Ethernet)
Amphenol Socapex KIT40792NI	Plug	Bulkhead Panel Mount	Shielded	Does Not Contain LED	Solder	1		1	Circular Threaded Coupling Heat Shrink Tubing	User Selectable	90 °	8p8c (RJ45 Ethernet)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Jack Modular Connector Straight Shielded

Technical documentation and resources
