TRA3225

Obsolete

ON Semiconductor

MEDIUM-CURRENT SILICON RECTIFIER

Search across all available documentation for this part.

Obsolete

ON Semiconductor

MEDIUM-CURRENT SILICON RECTIFIER

Technical Specifications

Parameters and characteristics for this part

Specification	TRA3225

Current - Average Rectified (Io)	32 A
Current - Reverse Leakage @ Vr	20 µA
Mounting Type	Surface Mount
Operating Temperature - Junction [Max]	175 ░C
Operating Temperature - Junction [Min]	-65 C
Package / Case	Microde Button
Speed	Standard Recovery >500ns
Speed	200 mA
Supplier Device Package	Microde Button
Technology	Standard
Voltage - DC Reverse (Vr) (Max) [Max]	250 V
Voltage - Forward (Vf) (Max) @ If	1.15 V

Medium-Current Silicon Rectifier

Part	Technology	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max) [Max]	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Speed	Speed	Supplier Device Package	Package / Case	Voltage - Forward (Vf) (Max) @ If	Current - Average Rectified (Io)	Mounting Type
ON Semiconductor TRA3225	Standard	20 µA	250 V	175 ░C	-65 C	Standard Recovery >500ns	200 mA	Microde Button	Microde Button	1.15 V	32 A	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

250 Volts, 32 AmperesCompact, highly efficient silicon rectifiers for medium-current applications requiring:
