TD-88122

Active

Macromatic Industrial Controls

RELAY TIME DEL 10230HR 10A 240V

Search across all available documentation for this part.

Active

Macromatic Industrial Controls

RELAY TIME DEL 10230HR 10A 240V

Technical Specifications

Parameters and characteristics for this part

Specification	TD-88122

Circuit	DPDT (2 Form C)
Contact Rating @ Voltage	240 VAC, 30 VDC, 10 A
Delay Time [Max]	10230 Hrs
Delay Time [Min]	0.05 Sec
Function	Programmable (Multi-Function)
Mounting Type	Socketable
Relay Type	Mechanical Relay
Termination Style	Plug In, 11 Pin (Octal)
Timing Adjustment Method	DIP Switches
Timing Initiate Method	Input Voltage
Voltage - Supply	120 VAC

Part	Circuit	Relay Type	Timing Initiate Method	Mounting Type	Timing Adjustment Method	Function	Delay Time [Max]	Delay Time [Min]	Contact Rating @ Voltage	Voltage - Supply	Termination Style
Macromatic Industrial Controls TD-88122	DPDT (2 Form C)	Mechanical Relay	Input Voltage	Socketable	DIP Switches	Programmable (Multi-Function)	10230 Hrs	0.05 Sec	10 A 30 VDC 240 VAC	120 VAC	Plug In 11 Pin (Octal)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 120.35

General part information

Programmable (Multi-Function) Time Delay Relay DPDT (2 Form C) 0.05 Sec ~ 10230 Hrs Delay 10A @ 240VAC/30VDC Socketable

Technical documentation and resources

No documents available
