AZEV140-1AE-24D

Active

American Zettler

RELAY EV CHARGING SPST 50A 24V

Search across all available documentation for this part.

Active

American Zettler

RELAY EV CHARGING SPST 50A 24V

Technical Specifications

Parameters and characteristics for this part

Part	Switching Voltage	Operate Time	Mounting Type	Approval Agency	Contact Form	Contact Material	Coil Voltage	Contact Rating (Current)	Termination Style	Termination Style	Coil Resistance	Coil Insulation	Load - Max Switching	Must Release Voltage	Coil Type	Release Time	Relay Type	Operating Temperature [Max]	Operating Temperature [Min]	Must Operate Voltage	Coil Current
American Zettler AZEV140-1AE-12D	440 VAC	30 ms	Through Hole	CQC cURus TUV	SPST-NO (1 Form A)	Silver Tin Oxide (AgSnO)	12 VDC	50 A	0.187 in 4.7 mm	PC Pin Quick Connect	68.5 Ohms	Class F	22000 VA	0.6 VDC	Non Latching	10 ms	EV Charging	85 °C	-40 °C	9 VDC	175.2 mA
American Zettler AZEV140-1AE-24D	440 VAC	30 ms	Through Hole	CQC cURus TUV	SPST-NO (1 Form A)	Silver Tin Oxide (AgSnO)	24 VDC	50 A	0.187 in 4.7 mm	PC Pin Quick Connect	274 Ohms	Class F	22000 VA	1.2 VDC	Non Latching	10 ms	EV Charging	85 °C	-40 °C	18 VDC	87.6 mA
American Zettler AZEV140-1AE1BG-12D	440 VAC	30 ms	Through Hole	CQC cURus TUV	DPST-NO/NC	Gold (Au) Silver Nickel (AgNi) Silver Tin Oxide (AgSnO)	12 VDC	50 A	0.187 in 4.7 mm	PC Pin Quick Connect	68.5 Ohms	Class F	22000 VA	0.6 VDC	Non Latching	10 ms	EV Charging	85 °C	-40 °C	9 VDC	175.2 mA
American Zettler AZEV140-1AE1BG-5D	440 VAC	30 ms	Through Hole	CQC cURus TUV	DPST-NO/NC	Gold (Au) Silver Nickel (AgNi) Silver Tin Oxide (AgSnO)	5 VDC	50 A	0.187 in 4.7 mm	PC Pin Quick Connect	11.8 Ohms	Class F	22000 VA	0.25 VDC	Non Latching	10 ms	EV Charging	85 °C	-40 °C	3.75 VDC	423.7 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	400	$ 6.71

General part information

EV Charging Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
