AT4125E

Obsolete

NKK Switches

CAP ROCKER RECT BLACK/YELLOW

Search across all available documentation for this part.

Obsolete

NKK Switches

CAP ROCKER RECT BLACK/YELLOW

Technical Specifications

Parameters and characteristics for this part

Specification	AT4125E

Color	Black, Yellow Lens
For Use With/Related Products	MLW Series
Illumination	Illuminated
Mounting Type	Snap Fit
Shape	Concave, Rectangular
Size [x]	16 mm
Size [y]	12.6 mm
Size [z]	10.5 mm
Switch Type	Rocker

Part	Illumination	For Use With/Related Products	Mounting Type	Switch Type	Color	Size [y]	Size [x]	Size [z]	Shape
NKK Switches AT4125C	Illuminated	MLW Series	Snap Fit	Rocker	Black Red Lens	12.6 mm	16 mm	10.5 mm	Concave Rectangular
NKK Switches AT4125E	Illuminated	MLW Series	Snap Fit	Rocker	Black Yellow Lens	12.6 mm	16 mm	10.5 mm	Concave Rectangular

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Rectangular, Concave Rocker Switch Cap Black, Yellow Lens Snap Fit
