AMI-M11K-7-5-B-1

Active

Altran Magnetics, LLC

LINE FILTER 250VAC 5A CHASSIS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AMI-M11K-7-5-B-1

Active

Altran Magnetics, LLC

LINE FILTER 250VAC 5A CHASSIS

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AMI-M11K-7-5-B-1

Applications	General Purpose
Configuration	Single Stage
Current	5 A
Filter Type	Single Phase
Frequency - Operating [Max]	60 Hz
Frequency - Operating [Min]	50 Hz
Inductance	516 µH
Mounting Type	Chassis Mount
Operating Temperature [Max]	40 °C
Operating Temperature [Min]	-10 °C
Termination Style	Quick Connect, IEC 320-C14
Voltage - Rated AC	250 V

AMI-M11K Series

Part	Applications	Inductance	Filter Type	Mounting Type	Termination Style	Configuration	Frequency - Operating [Max]	Frequency - Operating [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Current	Voltage - Rated AC
Altran Magnetics, LLC AMI-M11K-7M-10-B-2	General Purpose	495 µH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	10 A	250 V
Altran Magnetics, LLC AMI-M11K-7-3-B-2	General Purpose	1.76 mH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	3 A	250 V
Altran Magnetics, LLC AMI-M11K-7M-5-B-1	General Purpose	516 µH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	5 A	250 V
Altran Magnetics, LLC AMI-M11K-7-5-B-1	General Purpose	516 µH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	5 A	250 V
Altran Magnetics, LLC AMI-M11K-7-3-B-1	General Purpose	1.76 mH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	3 A	250 V
Altran Magnetics, LLC AMI-M11K-7-5-B-2	General Purpose	516 µH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	5 A	250 V
Altran Magnetics, LLC AMI-M11K-7M-5-B-2	General Purpose	516 µH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	5 A	250 V
Altran Magnetics, LLC AMI-M11K-7M-10-B-1	General Purpose	495 µH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	10 A	250 V
Altran Magnetics, LLC AMI-M11K-7-20-B	General Purpose	440 µH	Single Phase	Chassis Mount	IEC 320-C20 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	20 A	250 V
Altran Magnetics, LLC AMI-M11K-7M-3-B-1	General Purpose	1.76 mH	Single Phase	Chassis Mount	IEC 320-C14 Quick Connect	Single Stage	60 Hz	50 Hz	-10 °C	40 °C	3 A	250 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 16.68
		10	$ 13.61
		25	$ 12.55
		50	$ 11.80

Description

General part information

AMI-M11K Series

Single Phase EMC/EMI Line Filter 5 A 250V 50/60Hz Single Stage IEC 320-C14, Quick Connect

Documents

Technical documentation and resources
