A3B-12PA-2DSA(71)

Obsolete

Hirose Electric USA, Inc.

CONN HEADER VERT 12POS 2MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

A3B-12PA-2DSA(71)

Obsolete

Hirose Electric USA, Inc.

CONN HEADER VERT 12POS 2MM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	A3B-12PA-2DSA(71)

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	Flash
Contact Finish Thickness - Post	2 çm
Contact Finish Thickness - Post	78.7 çin
Contact Length - Mating	0.138 in
Contact Length - Mating	3.5 mm
Contact Length - Post	0.102 in
Contact Length - Post	2.6 mm
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	1.8 mm
Insulation Height	0.071 "
Insulation Material	Polyamide (PA), Nylon
Mated Stacking Heights	8.8 mm, 6 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	12
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-55 °C
Overall Contact Length	7.9 mm
Overall Contact Length	0.311 in
Pitch - Mating [x]	0.079 in
Pitch - Mating [x]	2 mm
Row Spacing - Mating	0.079 in
Row Spacing - Mating	2 mm
Shrouding	Unshrouded
Style	Board to Board, Cable
Termination	Solder

A3B-12PA Series

Part	Pitch - Mating [x]	Pitch - Mating [x]	Insulation Height [custom]	Insulation Height [custom]	Fastening Type	Contact Length - Mating	Contact Length - Mating	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions Loaded	Contact Shape	Number of Positions	Connector Type	Contact Finish - Post	Contact Finish - Mating	Termination	Number of Rows	Contact Finish Thickness - Mating	Style	Material Flammability Rating	Contact Length - Post	Contact Length - Post	Mounting Type	Insulation Color	Contact Type	Insulation Material	Contact Material	Shrouding	Row Spacing - Mating	Row Spacing - Mating	Insulation Height	Insulation Height	Overall Contact Length	Overall Contact Length	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Mated Stacking Heights
Hirose Electric USA, Inc. A3B-12PA-2DS(71)	0.079 in	2 mm	0.157 in	4 mm	Push-Pull	0.138 in	3.5 mm	85 °C	-55 °C	All	Square	12	Header	Tin	Gold	Kinked Pin Solder	2	Flash	Board to Board Cable	UL94 V-0	0.102 in	2.6 mm	Through Hole Right Angle	Black	Male Pin	Nylon Polyamide (PA)	Brass	Unshrouded	0.079 in	2 mm
Hirose Electric USA, Inc. A3B-12PA-2DSA(71)	0.079 in	2 mm			Push-Pull	0.138 in	3.5 mm	85 °C	-55 °C	All	Square	12	Header	Tin	Gold	Solder	2	Flash	Board to Board Cable	UL94 V-0	0.102 in	2.6 mm	Through Hole	Black	Male Pin	Nylon Polyamide (PA)	Brass	Unshrouded	0.079 in	2 mm	1.8 mm	0.071 "	7.9 mm	0.311 in	2 çm	78.7 çin	6 mm 8.8 mm
Hirose Electric USA, Inc. A3B-12PA-2DS(51)	0.079 in	2 mm	0.157 in	4 mm	Push-Pull	0.138 in	3.5 mm	85 °C	-55 °C	All	Square	12	Header		Gold	Kinked Pin Solder	2		Board to Board Cable	UL94 V-0	0.102 in	2.6 mm	Through Hole Right Angle	Black	Male Pin	Nylon Polyamide (PA)	Brass	Unshrouded	0.079 in	2 mm
