DB-C8-J10-F5-1R

Active

JAE Electronics

DSUB JUNCTION SHELL

Search across all available documentation for this part.

Active

JAE Electronics

DSUB JUNCTION SHELL

Technical Specifications

Parameters and characteristics for this part

Specification	DB-C8-J10-F5-1R

Accessory Type	Two Piece Backshell
Cable Exit	180 °
Cable Type	Round
Compatible D-Sub Size	HD44pos, 25pos
Compatible Shell Size	B
Features	Mating Screws 4-40
Material	Acrylonitrile Butadiene Styrene (ABS)
Primary Material	Plastic
Shielding	Unshielded

Part	Cable Type	Cable Exit	Compatible Shell Size	Shielding	Compatible D-Sub Size	Accessory Type	Features	Material	Primary Material	Color	Plating
JAE Electronics DB-C8-J10-B2-1R	Round	180 °	B	Unshielded	25pos HD44pos	Two Piece Backshell	Mating Screws 4-40	Acrylonitrile Butadiene Styrene (ABS)	Plastic
JAE Electronics DB-C8-J10-F1-1R	Round	180 °	B	Unshielded	25pos HD44pos	Two Piece Backshell	Mating Screws M2.6 Spring Lock	Acrylonitrile Butadiene Styrene (ABS)	Plastic	Silver	Nickel
JAE Electronics DB-C8-J10-F5-1R	Round	180 °	B	Unshielded	25pos HD44pos	Two Piece Backshell	Mating Screws 4-40	Acrylonitrile Butadiene Styrene (ABS)	Plastic
JAE Electronics DB-C8-J10-F2-1R	Round	180 °	B	Unshielded	25pos HD44pos	Two Piece Backshell	Mating Screws 4-40 Spring Lock	Acrylonitrile Butadiene Styrene (ABS)	Plastic	Silver	Nickel
JAE Electronics DB-C8-J10-F4-1R	Round	180 °	B	Unshielded	25pos HD44pos	Two Piece Backshell	Mating Screws M2.6	Acrylonitrile Butadiene Styrene (ABS)	Plastic
JAE Electronics DB-C8-J10-B1-1R	Round	180 °	B	Unshielded	25pos HD44pos	Two Piece Backshell	Mating Screws M2.6	Acrylonitrile Butadiene Styrene (ABS)	Plastic

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

25 Position Two Piece Backshell Connector 180° Unshielded
