50HV26B123KC - 50HV26N102KNM

50HV26B123KC

Active
KEMET

CAP CER 0.012UF 5KV X7R RADIAL

Deep-Dive with AI

Search across all available documentation for this part.

Documents50HV26B123KC SpecDatasheet+1
50HV26B123KC - 50HV26N102KNM

50HV26B123KC

Active
KEMET

CAP CER 0.012UF 5KV X7R RADIAL

Deep-Dive with AI

Documents50HV26B123KC SpecDatasheet+1

Technical Specifications

Parameters and characteristics for this part

Specification50HV26B123KC
ApplicationsSMPS Filtering
Capacitance0.012 µF
FeaturesHigh Voltage
Lead Spacing17.14 mm
Lead Spacing0.675 in
Lead StyleStraight
Mounting TypeThrough Hole
Operating Temperature [Max]125 °C
Operating Temperature [Min]-55 °C
Package / CaseRadial
Size / Dimension [x]0.77 in
Size / Dimension [x]19.56 mm
Size / Dimension [y]0.271 "
Size / Dimension [y]6.89 mm
Temperature CoefficientX7R
Tolerance10 %
Voltage - Rated5 kV
Voltage - Rated5 kV

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$

Description

General part information

50HV26B Series

0.012 µF ±10% 5000V (5kV) Ceramic Capacitor X7R Radial
