AA60S2400A

Obsolete

Delta Electronics

AC/DC POWER SUPPLY SINGLE-OUT 24V 2.5A 60W 4-PIN

Search across all available documentation for this part.

Obsolete

Delta Electronics

AC/DC POWER SUPPLY SINGLE-OUT 24V 2.5A 60W 4-PIN

Technical Specifications

Parameters and characteristics for this part

Part	Efficiency	Mounting Type	Number of Outputs	Features	Current - Output (Max) [Max]	Approval Agency	Type	Package / Case	Standard Number	Line Regulation	Power (Watts)	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Weight	Weight	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Voltage - Output 1	Load Regulation	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Voltage - Isolation	Current - Output 1
Delta Electronics AA60S1500A	83 %	Through Hole	1	Universal Input	4 A	CE UL	Enclosed	6-DIP Module 4 Leads	60950-1	±0.2%	60 W	34.2 mm	88.9 mm	2.66 "	3.5 in	67.5 mm	1.35 "	0.761 lb	345.18 g	-10 °C	70 °C	ITE (Commercial)	15 V	0.5 %
Delta Electronics AA60S1500C	83 %	Chassis Mount	1	DC Input Capable Universal Input		CE	Enclosed					38 mm	112 mm	2.67 in	4.41 "	67.8 mm	1.5 "					ITE (Commercial)	15 V		-10 °C	158 °F	3000 V	4 A
Delta Electronics AA60S2400A	84 %	Through Hole	1	Universal Input	2.5 A	CE UL	Enclosed	6-DIP Module 4 Leads	60950-1	±0.2%	60 W	34.2 mm	88.9 mm	2.66 "	3.5 in	67.5 mm	1.35 "	0.761 lb	345.18 g	-10 °C	70 °C	ITE (Commercial)	24 V	0.5 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 1 Output 24V 2.5A 85 ~ 264 VAC Input
