5962-8683901SA
ActiveMILITARY 8-CH, 4.5-V TO 5.5-V BIPOLAR BUFFERS WITH 3-STATE OUTPUTS
Deep-Dive with AI
Search across all available documentation for this part.
5962-8683901SA
ActiveMILITARY 8-CH, 4.5-V TO 5.5-V BIPOLAR BUFFERS WITH 3-STATE OUTPUTS
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 5962-8683901SA |
|---|---|
| null | |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 8 | $ 40.30 | |
| Texas Instruments | TUBE | 1 | $ 53.26 | |
| 100 | $ 46.52 | |||
| 250 | $ 35.87 | |||
| 1000 | $ 32.09 | |||
Description
General part information
5962-86839012 Series
These octal buffers and line drivers are designed specifically to improve the performance and density of 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters. With the ´ALS240A, ´ALS241C, ´AS240A, and ´AS241A, these devices provide the choice of selected combinations of inverting outputs, symmetrical active-low output-enable () inputs, and complementary OE andinputs.
The -1 version of SN74ALS244C is identical to the standard version, except that the recommended maximum IOLfor the -1 version is 48 mA. There is no -1 version of the SN54ALS244C.
The SN54ALS244C and SN54AS244A are characterized for operation over the full military temperature range of -55°C to 125°C. The SN74ALS244C and SN74AS244A are characterized for operation from 0°C to 70°C.
