7-1423008-5
ActiveTE Connectivity Potter & Brumfield Relays
T92HS7D1X-24
Deep-Dive with AI
Search across all available documentation for this part.
7-1423008-5
ActiveTE Connectivity Potter & Brumfield Relays
T92HS7D1X-24
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 7-1423008-5 |
|---|---|
| Coil Current | 68.6 mA |
| Coil Insulation | Class F |
| Coil Resistance | 350 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 24 VDC |
| Contact Form | DPST-NO (2 Form A) |
| Contact Material | Silver Alloy, Cadmium Free |
| Contact Rating (Current) | 50 A |
| Load - Max Switching [Max] | 30000 VA |
| Mounting Type | Through Hole |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 25 ms |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -55 °C |
| Relay Type | General Purpose |
| Release Time | 25 ms |
| Seal Rating | Sealed - Fully |
| Switching Voltage | 600 VAC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 37.99 | |
| 10 | $ 33.19 | |||
| 25 | $ 31.45 | |||
| 40 | $ 30.59 | |||
| 80 | $ 29.37 | |||
| 230 | $ 27.60 | |||
Description
General part information
1423008 Series
General Purpose Relay DPST-NO (2 Form A) 24VDC Coil Through Hole
