5PB1216NDGK
ActiveRenesas Electronics Corporation
IC CLK BUFFER 1:6 200MHZ 20QFN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
5PB1216NDGK
ActiveRenesas Electronics Corporation
IC CLK BUFFER 1:6 200MHZ 20QFN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 5PB1216NDGK |
|---|---|
| Differential - Input:Output | False |
| Frequency - Max [Max] | 200 MHz |
| Input | LVCMOS |
| Mounting Type | Surface Mount |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 105 °C |
| Operating Temperature [Min] | -40 °C |
| Output | LVCMOS |
| Package / Case | 20-VFQFN Exposed Pad |
| Ratio - Input:Output [custom] | 1:6 |
| Supplier Device Package | 20-QFN (3x3) |
| Type | Clock Buffer |
| Voltage - Supply [Max] | 3.465 V, 2.625 V, 1.89 V |
| Voltage - Supply [Min] | 2.375 V, 1.71 V, 3.135 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 3.07 | |
| 10 | $ 2.30 | |||
| 25 | $ 2.11 | |||
| 100 | $ 1.90 | |||
| 250 | $ 1.80 | |||
| 624 | $ 1.72 | |||
| 1248 | $ 1.67 | |||
| 3120 | $ 1.62 | |||
| 5616 | $ 1.60 | |||
Description
General part information
5PB1216 Series
Clock Clock Buffer IC 1:6 200 MHz 20-VFQFN Exposed Pad
