M13507 SL001

Active

ALPHA WIRE

CABLE 7COND 18AWG SLATE 1000'

Search across all available documentation for this part.

Active

ALPHA WIRE

CABLE 7COND 18AWG SLATE 1000'

Technical Specifications

Parameters and characteristics for this part

Specification	M13507 SL001

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	16
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	8.46 mm
Jacket (Insulation) Diameter [diameter]	0.333 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.94 mm
Jacket (Insulation) Thickness	0.037 in
Jacket Color	Slate
Length	1000 ft
Length	304.8 m
Number of Conductors	7
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Ratings	UL Style 2598
Voltage	300 V
Wire Gauge	18 AWG

Part	Conductor Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Conductor Strand [custom]	Conductor Strand [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Cable Type	Number of Conductors	Length	Length	Voltage	Wire Gauge	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Insulation	Ratings
ALPHA WIRE M13507 SL001	Copper Tinned	0.94 mm	0.037 in	Slate	16	30 AWG	-20 C	80 C	Multi-Conductor	7	1000 ft	304.8 m	300 V	18 AWG	Poly-Vinyl Chloride (PVC)	8.46 mm	0.333 in	Poly-Vinyl Chloride (PVC)	UL Style 2598

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

7 Conductor Multi-Conductor Cable Slate 18 AWG 1000.0' (304.8m)
