RSDW20UW-05

Active

MEAN WELL USA Inc.

DC/DC MODULE 20W,I/P: 8.5-160VDC

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

DC/DC MODULE 20W,I/P: 8.5-160VDC

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Voltage - Input (Max) [Max]	Voltage - Isolation	Voltage - Output 1	Package / Case	Power (Watts)	Applications	Current - Output (Max) [Max]	Efficiency	Number of Outputs	Features	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input (Min) [Min]	Type	Approval Agency	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]
MEAN WELL USA Inc. RSDW20UW-12	Through Hole	160 V	3000 V	12 V	6-DIP Module	20 W	ITE (Commercial) Railway	1.67 A	89 %	1	Remote On/Off	-40 °C	95 °C	8.5 V	Isolated Module	CE cURus EAC UL	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm
MEAN WELL USA Inc. RSDW20UW-05	Through Hole	160 V	3000 V	5 V	6-DIP Module	20 W	ITE (Commercial) Railway	4 A	85.5 %	1	Remote On/Off	-40 °C	95 °C	8.5 V	Isolated Module	CE cURus EAC UL	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 62.94

General part information

Isolated Module DC DC Converter 1 Output 5V 4A 8.5V - 160V Input
