1813A B59328

Active

Belden Inc.

2 #24 PVC SRV PVC

Search across all available documentation for this part.

Active

Belden Inc.

2 #24 PVC SRV PVC

Technical Specifications

Parameters and characteristics for this part

Specification	1813A B59328

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Bare
Conductor Strand [custom]	38 AWG
Conductor Strand [custom]	27 Strands
Jacket (Insulation) Diameter [diameter]	5.99 mm
Jacket (Insulation) Diameter [diameter]	0.236 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	1.397 mm
Jacket (Insulation) Thickness	0.055 in
Jacket Color	Black
Length	100 m
Length	328.1 ft
Number of Conductors	2
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-30 ░C
Shield Coverage	90 %
Shield Material	Copper, Bare
Shield Type	Spiral
Usage	Audio
Wire Gauge	24 AWG

Part	Shield Type	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Insulation	Number of Conductors	Operating Temperature [Min]	Operating Temperature [Max]	Cable Type	Length	Length	Wire Gauge	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Shield Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Shield Coverage	Jacket (Insulation) Material	Jacket Color	Usage	Conductor Material
Belden Inc. 1813A B59328	Spiral	38 AWG	27 Strands	Poly-Vinyl Chloride (PVC)	2	-30 ░C	60 °C	Multi-Conductor	100 m	328.1 ft	24 AWG	1.397 mm	0.055 in	Copper Bare	5.99 mm	0.236 in	90 %	Poly-Vinyl Chloride (PVC)	Black	Audio	Copper Bare

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	328	$ 1.61

General part information

2 Conductor Multi-Conductor Cable Black 24 AWG Spiral 328.1' (100.0m)
