XC705B32CBE
ObsoleteFreescale Semiconductor - NXP
IC MCU 8BIT 32KB OTP 56PSDIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
XC705B32CBE
ObsoleteFreescale Semiconductor - NXP
IC MCU 8BIT 32KB OTP 56PSDIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | XC705B32CBE |
|---|---|
| Connectivity | SCI |
| Core Processor | HC05 |
| Core Size | 8-Bit |
| Data Converters | D/A 2x8b, A/D 8x8b |
| EEPROM Size | 256 x 8 |
| Mounting Type | Through Hole |
| Number of I/O | 32 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Oscillator Type | Internal |
| Package / Case | 0.6 in |
| Package / Case | 56-SDIP |
| Package / Case | 15.24 mm |
| Peripherals | WDT, POR |
| Program Memory Size | 32 KB |
| Program Memory Type | OTP |
| RAM Size | 528 |
| Speed | 2.1 MHz |
| Voltage - Supply (Vcc/Vdd) [Max] | 5.5 V |
| Voltage - Supply (Vcc/Vdd) [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
XC70 Series
HC05 HC05 Microcontroller IC 8-Bit 2.1MHz 32KB (32K x 8) OTP 56-PSDIP
