WP26-P040VA1-R15000
ActiveJAE Electronics
CONN PLUG 40POS SMD GOLD
Deep-Dive with AI
Search across all available documentation for this part.
WP26-P040VA1-R15000
ActiveJAE Electronics
CONN PLUG 40POS SMD GOLD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | WP26-P040VA1-R15000 |
|---|---|
| Connector Type | Outer Shroud Contacts, Plug |
| Contact Finish | Gold |
| Contact Finish Thickness | 4 Áin |
| Contact Finish Thickness | 0.1 Ám |
| Features | Solder Retention |
| Height Above Board [z] | 0.48 mm |
| Height Above Board [z] | 0.019 " |
| Mated Stacking Heights | 0.6 mm |
| Mounting Type | Surface Mount |
| Number of Positions | 40 |
| Number of Rows | 2 |
| Pitch [x] | 0.35 mm |
| Pitch [x] | 0.014 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.58 | |
| 10 | $ 1.38 | |||
| 25 | $ 1.32 | |||
| 50 | $ 1.29 | |||
| 100 | $ 1.23 | |||
| 250 | $ 1.11 | |||
| 500 | $ 1.03 | |||
| 1000 | $ 0.88 | |||
| 2500 | $ 0.82 | |||
| Digi-Reel® | 1 | $ 1.58 | ||
| 10 | $ 1.38 | |||
| 25 | $ 1.32 | |||
| 50 | $ 1.29 | |||
| 100 | $ 1.23 | |||
| 250 | $ 1.11 | |||
| 500 | $ 1.03 | |||
| 1000 | $ 0.88 | |||
| 2500 | $ 0.82 | |||
| Tape & Reel (TR) | 15000 | $ 0.76 | ||
Description
General part information
WP26-P04 Series
40 Position Connector Plug, Outer Shroud Contacts Surface Mount Gold
