XTR108EVM-USB
ActiveEVAL MODULE FOR XTR108-USB
Deep-Dive with AI
Search across all available documentation for this part.
XTR108EVM-USB
ActiveEVAL MODULE FOR XTR108-USB
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | XTR108EVM-USB |
|---|---|
| Function | Transmitter |
| Function [Max] | 20 mA |
| Function [Min] | 4 mA |
| Supplied Contents | Cable(s), Board(s) |
| Type | Interface |
| Utilized IC / Part | XTR108 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 478.80 | |
Description
General part information
XTR108 Series
The XTR108 is a "smart", programmable, 4-20mA, two-wire transmitter designed for temperature and bridge sensors. Zero, span, and linearization errors in the analog signal path can be calibrated via a standard digital serial interface, eliminating manual trimming. Non-volatile ex-ternal EEPROM stores calibration settings.
The all-analog signal path contains an input multiplexer, autozeroed programmable-gain instrumentation amplifier, dual programmable current sources, linearization circuit, voltage reference, sub-regulator, internal oscillator, control logic, and an output current amplifier. Programmable level shifting compensates for sensor DC offsets. Selectable up- and down-scale output indicates out-of-range and burn-out per NAMUR NE43. Automatic reset is initiated when supply is lost.
The XTR108 is a "smart", programmable, 4-20mA, two-wire transmitter designed for temperature and bridge sensors. Zero, span, and linearization errors in the analog signal path can be calibrated via a standard digital serial interface, eliminating manual trimming. Non-volatile ex-ternal EEPROM stores calibration settings.
