CI2506P1V00-LF

Obsolete

Cvilux USA

6 POS 2.50MM (.098) WIRE TO BOAR

Search across all available documentation for this part.

Obsolete

Cvilux USA

6 POS 2.50MM (.098) WIRE TO BOAR

Technical Specifications

Parameters and characteristics for this part

Specification	CI2506P1V00-LF

Connector Type	Header
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	120 µin
Contact Finish Thickness - Mating	3.05 Ám
Contact Finish Thickness - Post	120 Áin
Contact Finish Thickness - Post	3.05 Ám
Contact Length - Post [x]	0.134 in
Contact Length - Post [x]	3.4 mm
Contact Material	Brass
Contact Shape	Circular
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Detent Lock
Insulation Color	Natural
Insulation Height	5.9 mm
Insulation Height	0.232 in
Insulation Material	Polyamide (PA46), Nylon 4/6
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	6
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Overall Contact Length	0.35 in
Overall Contact Length	8.89 mm
Pitch - Mating	2.5 mm
Pitch - Mating	0.098 in
Shrouding	Shrouded - 4 Wall
Style	Board to Cable/Wire
Termination	Solder
Voltage Rating	50 VAC

Part	Insulation Height	Insulation Height	Number of Rows	Fastening Type	Contact Shape	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Color	Voltage Rating	Connector Type	Current Rating (Amps)	Overall Contact Length	Overall Contact Length	Shrouding	Number of Positions Loaded	Contact Finish - Post	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Type	Contact Length - Post [x]	Contact Length - Post [x]	Mounting Type	Style	Termination	Contact Material	Insulation Material	Number of Positions
Cvilux USA CI2506P1V00-LF	5.9 mm	0.232 in	1	Detent Lock	Circular	120 µin	3.05 Ám	120 Áin	3.05 Ám	Natural	50 VAC	Header	3 A	0.35 in	8.89 mm	Shrouded - 4 Wall	All	Tin	2.5 mm	0.098 in	UL94 V-0	-25 °C	85 °C	Male Pin	0.134 in	3.4 mm	Through Hole	Board to Cable/Wire	Solder	Brass	Polyamide (PA46) Nylon 4/6	6
Cvilux USA CI2506P1H00-LF	4.9 mm	0.193 in	1	Detent Lock	Circular	120 µin	3.05 Ám	120 Áin	3.05 Ám	Ivory	250 VAC	Header	3 A			Shrouded - 4 Wall	All	Tin	2.5 mm	0.098 in	UL94 V-0	-25 °C	85 °C	Male Pin	0.134 in	3.4 mm	Through Hole Right Angle	Board to Cable/Wire	Solder	Brass	Polyamide (PA46) Nylon 4/6	6
