52106C

Active

Murata Power Solutions Inc.

CMC 1.7A 2LN TH

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

CMC 1.7A 2LN TH

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Filter Type	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case	Height (Max)	Height (Max) [Max]	DC Resistance (DCR) (Max)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Number of Lines	DC Resistance (DCR) (Max) [Max]	Current Rating (Max) [Max]
Murata Power Solutions Inc. 52106C	Through Hole	Power Line	125 °C	-40 °C	4 Lead	Vertical	31 mm	1.22 in	193 mOhm	16.3 mm	0.945 in	0.642 in	24 mm	2
Murata Power Solutions Inc. 52305C	Through Hole	Power Line	125 °C	-40 °C	4 Lead	Vertical	31 mm	1.22 in		16.3 mm	0.945 in	0.642 in	24 mm	2	45 mOhm	3.5 A
Murata Power Solutions Inc. 52505C	Through Hole	Power Line	125 °C	-40 °C	4 Lead	Vertical	31 mm	1.22 in		16.3 mm	0.945 in	0.642 in	24 mm	2	91 mOhm	2.4 A
Murata Power Solutions Inc. 52705C	Through Hole	Power Line	125 °C	-40 °C	4 Lead	Vertical	31 mm	1.22 in		16.3 mm	0.945 in	0.642 in	24 mm	2	107 mOhm	2.2 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Line Common Mode Choke Through Hole 1.7A DCR 193mOhm
