38H302C

Active

Murata Power Solutions Inc.

POWER INDUCTOR (SMD), 3 ΜH, 4.9 A, UNSHIELDED, 9.4 A, 3800 SERIES

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

POWER INDUCTOR (SMD), 3 ΜH, 4.9 A, UNSHIELDED, 9.4 A, 3800 SERIES

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Inductance	Tolerance	Current - Saturation (Isat)	Operating Temperature [Min]	Operating Temperature [Max]	Type	Package / Case	Shielding	Mounting Type	Inductance Frequency - Test	DC Resistance (DCR) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Current Rating (Amps)	DC Resistance (DCR)
Murata Power Solutions Inc. 38H122C	10.4 mm	0.409 in	0.409 "	10.4 mm	1.2 µH	20 %	17 A	-40 °C	130 °C	Wirewound	Nonstandard	Unshielded	Surface Mount	100 kHz	6.8 mOhm	0.22 in	5.6 mm
Murata Power Solutions Inc. 38H302C	10.4 mm	0.409 in	0.409 "	10.4 mm	3 ÁH	20 %	9.4 A	-40 °C	130 °C	Wirewound	Nonstandard	Unshielded	Surface Mount	100 kHz		0.22 in	5.6 mm	4.9 A	19.4 mOhm
Murata Power Solutions Inc. 38H151C	10.4 mm	0.409 in	0.409 "	10.4 mm	150 nH	30 %	38 A	-40 °C	130 °C	Wirewound	Nonstandard	Unshielded	Surface Mount	100 kHz	1.9 mOhm	0.22 in	5.6 mm	18 A
Murata Power Solutions Inc. 38H152C	10.4 mm	0.409 in	0.409 "	10.4 mm	1.5 µH	20 %	14 A	-40 °C	130 °C	Wirewound	Nonstandard	Unshielded	Surface Mount	100 kHz	9.5 mOhm	0.22 in	5.6 mm	7.2 A
Murata Power Solutions Inc. 38H301C	10.4 mm	0.409 in	0.409 "	10.4 mm	300 nH	30 %	32 A	-40 °C	130 °C	Wirewound	Nonstandard	Unshielded	Surface Mount	100 kHz	2.2 mOhm	0.22 in	5.6 mm	16 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	650	$ 0.96
Newark	Each (Supplied on Cut Tape)	500	$ 1.15
		1000	$ 1.11

General part information

3 µH Unshielded Wirewound Inductor 4.9 A 19.4mOhm Max Nonstandard
