BA5956FM-E2
ObsoleteRohm Semiconductor
IC HALF BRIDGE DRIVER 36HSOP
Deep-Dive with AI
Search across all available documentation for this part.
BA5956FM-E2
ObsoleteRohm Semiconductor
IC HALF BRIDGE DRIVER 36HSOP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BA5956FM-E2 |
|---|---|
| Applications | DC Motors, General Purpose |
| Fault Protection | Over Temperature, UVLO |
| Interface | Logic |
| Load Type | Inductive |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 C |
| Operating Temperature [Min] | -35 °C |
| Output Configuration | Half Bridge (10) |
| Package / Case | 0.295 in |
| Package / Case | 2 Heat Tabs, 36-SOP |
| Package / Case | 7.5 mm |
| Supplier Device Package | 36-HSOP-M |
| Technology | Bipolar |
| Voltage - Supply [Max] | 14 V |
| Voltage - Supply [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
BA5956 Series
Half Bridge (10) Driver DC Motors, General Purpose Bipolar 36-HSOP-M
