G8020E24B-RSR

Active

Mechatronics Bearing Group

FAN AXIAL 80X20.8MM 24VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsAC/DC Fans & Blowers Catalog DC Fan, Blower Lead Wire Spec +1

G8020E24B-RSR

Active

Mechatronics Bearing Group

FAN AXIAL 80X20.8MM 24VDC WIRE

Deep-Dive with AI

DocumentsAC/DC Fans & Blowers Catalog DC Fan, Blower Lead Wire Spec +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	G8020E24B-RSR

Air Flow	49 CFM
Air Flow	1.37 m³/min
Approval Agency	CE, cUL, TUV, UL
Bearing Type	Ball
Current Rating (Amps)	0.2 A
Fan Type	Tubeaxial
Features	Thermal Overload Protector (TOP)
Material - Blade	Polybutylene Terephthalate (PBT)
Noise	37 dB
RPM	4000 RPM
Size / Dimension [x]	80 mm
Size / Dimension [y]	80 mm
Static Pressure	49.8 Pa
Static Pressure	0.2 in H2O
Termination	2 Wire Leads
Voltage - Rated	24 VDC
Width [y]	20.8 mm

G8020 Series

Part	Air Flow	Air Flow	Width [y]	Size / Dimension [y]	Size / Dimension [x]	Noise	Material - Blade	RPM	Features	Approval Agency	Termination	Bearing Type	Current Rating (Amps)	Static Pressure	Static Pressure	Voltage - Rated	Fan Type
Mechatronics Bearing Group G8020H12B1+6-RSR	43 CFM	1.2 m³/min	20.8 mm	80 mm	80 mm	33 dB(A)	Polybutylene Terephthalate (PBT)	3500 RPM	PWM Control Speed Sensor (Tach) Thermal Overload Protector (TOP)	CE cUL TUV UL	4 Wire Leads	Ball	0.23 A	42.3 Pa	0.17 in H2O	12 VDC	Tubeaxial
Mechatronics Bearing Group G8020E24B1-RSR-WS	49 CFM	1.37 m³/min	20.8 mm	80 mm	80 mm	37 dB	Polybutylene Terephthalate (PBT)	4000 RPM	Alarm Sensor Speed Sensor (Tach) Thermal Overload Protector (TOP)	CE cUL TUV UL	4 Wire Leads	Ball	0.2 A	49.8 Pa	0.2 in H2O	24 VDC	Tubeaxial
Mechatronics Bearing Group G8020M12B-RSR	38 CFM	1.06 mł/min	20.8 mm	80 mm	80 mm	29 dB(A)	Polybutylene Terephthalate (PBT)	3000 RPM	Thermal Overload Protector (TOP)	CE cUL TUV UL	2 Wire Leads	Ball		32.4 Pa	0.13 in H2O	12 VDC	Tubeaxial
Mechatronics Bearing Group G8020E24B-RSR	49 CFM	1.37 m³/min	20.8 mm	80 mm	80 mm	37 dB	Polybutylene Terephthalate (PBT)	4000 RPM	Thermal Overload Protector (TOP)	CE cUL TUV UL	2 Wire Leads	Ball	0.2 A	49.8 Pa	0.2 in H2O	24 VDC	Tubeaxial
Mechatronics Bearing Group G8020S05B-RSR	24 CFM	0.672 mł/min	20.8 mm	80 mm	80 mm	22 dB(A)	Polybutylene Terephthalate (PBT)	2000 RPM	Thermal Overload Protector (TOP)	CE cUL TUV UL	2 Wire Leads	Ball	0.2 A	14.9 Pa	0.06 in H2O	5 V	Tubeaxial
Mechatronics Bearing Group G8020L12B1-RSR	31 CFM	0.868 mł/min	20.8 mm	80 mm	80 mm	25 dB(A)	Polybutylene Terephthalate (PBT)	2500 RPM	Speed Sensor (Tach) Thermal Overload Protector (TOP)	CE cUL TUV UL	3 Wire Leads	Ball	110 mA	24.9 Pa	0.1 in H2O	12 VDC	Tubeaxial
Mechatronics Bearing Group G8020S12B-RSR	24 CFM	0.672 mł/min	20.8 mm	80 mm	80 mm	22 dB(A)	Polybutylene Terephthalate (PBT)	2000 RPM	Thermal Overload Protector (TOP)	CE cUL TUV UL	2 Wire Leads	Ball	70 mA	14.9 Pa	0.06 in H2O	12 VDC	Tubeaxial
Mechatronics Bearing Group G8020L24B-RSR			20.8 mm	80 mm	80 mm	25 dB(A)	Polybutylene Terephthalate (PBT)	2500 RPM	Thermal Overload Protector (TOP)	CE cUL TUV UL	2 Wire Leads	Ball	75 mA	24.9 Pa	0.1 in H2O	24 VDC	Tubeaxial
Mechatronics Bearing Group G8020S12B1-RSR	24 CFM	0.672 mł/min	20.8 mm	80 mm	80 mm	22 dB(A)	Polybutylene Terephthalate (PBT)	2000 RPM	Speed Sensor (Tach) Thermal Overload Protector (TOP)	CE cUL TUV UL	3 Wire Leads	Ball	70 mA	14.9 Pa	0.06 in H2O	12 VDC	Tubeaxial
Mechatronics Bearing Group G8020M05B-RSR	38 CFM	1.06 mł/min	20.8 mm	80 mm	80 mm	29 dB(A)	Polybutylene Terephthalate (PBT)	3000 RPM	Thermal Overload Protector (TOP)	CE cUL TUV UL	2 Wire Leads	Ball	400 mA	32.4 Pa	0.13 in H2O	5 V	Tubeaxial

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 8.77

Description

General part information

G8020 Series

Fan Tubeaxial 24VDC Square - 80mm L x 80mm H Ball 49.0 CFM (1.37mł/min) 2 Wire Leads

Documents

Technical documentation and resources

AC/DC Fans & Blowers Catalog

Datasheet

DC Fan, Blower Lead Wire Spec

Datasheet
