CFM-5015V-138-201

Active

CUI Devices

FAN AXIAL 50X15MM 12VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CFM-5015V-138-201

Active

CUI Devices

FAN AXIAL 50X15MM 12VDC WIRE

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CFM-5015V-138-201

Air Flow	10.2 CFM
Air Flow	0.286 mł/min
Approval Agency	cURus, CE, TUV
Current Rating (Amps)	0.042 A
Fan Type	Tubeaxial
Features	Auto Restart
Lifetime @ Temp.	70000 Hrs
Material - Blade	Polybutylene Terephthalate (PBT)
Noise	20.1 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	0.4 W
RPM	3800 RPM
Size / Dimension [x]	50 mm
Size / Dimension [z]	50 mm
Static Pressure	29.9 Pa
Static Pressure	0.12 in H2O
Termination	2 Wire Leads
Voltage - Rated	12 VDC
Voltage Range [Max]	13.8 VDC
Voltage Range [Min]	4.5 V
Weight	33.11 g
Weight	0.073 lb
Width [x]	15 mm

CFM-5015 Series

Part	Material - Blade	Size / Dimension [z]	Size / Dimension [x]	Fan Type	Current Rating (Amps)	RPM	Weight	Weight	Lifetime @ Temp.	Width [x]	Noise	Air Flow	Air Flow	Features	Static Pressure	Static Pressure	Power (Watts)	Termination	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Approval Agency	Voltage - Rated	Voltage Range [Min]	Voltage Range [Max]
CUI Devices CFM-5015V-258-330	Polybutylene Terephthalate (PBT)	50 mm	50 mm	Tubeaxial	0.051 A	6100 RPM	33.11 g	0.073 lb	70000 Hrs	15 mm	33 dB(A)	17 CFM	0.476 m³/min	Auto Restart	0.23 in H2O	57.3 Pa	1.23 W	2 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	24 VDC
CUI Devices CFM-5015V-138-201	Polybutylene Terephthalate (PBT)	50 mm	50 mm	Tubeaxial	0.042 A	3800 RPM	33.11 g	0.073 lb	70000 Hrs	15 mm	20.1 dB	10.2 CFM	0.286 mł/min	Auto Restart	0.12 in H2O	29.9 Pa	0.4 W	2 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	12 VDC	4.5 V	13.8 VDC
CUI Devices CFM-5015V-150-290-20	Polybutylene Terephthalate (PBT)	50 mm	50 mm	Tubeaxial	0.054 A	5000 RPM	33.11 g	0.073 lb	70000 Hrs	15 mm	29 dB(A)	13 CFM	0.364 mł/min	Auto Restart Speed Sensor (Tach)	0.17 in H2O	42.3 Pa	0.65 W	3 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	12 VDC	4.5 V	13.8 VDC
CUI Devices CFM-5015V-161-330-11	Polybutylene Terephthalate (PBT)	50 mm	50 mm	Tubeaxial	0.083 A	6100 RPM	33.11 g	0.073 lb	70000 Hrs	15 mm	33 dB(A)	17 CFM	0.476 m³/min	Auto Restart Locked Rotor Sensor	0.23 in H2O	57.3 Pa	920 mW	3 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	12 VDC	4.5 V	13.8 VDC
CUI Devices CFM-5015V-132-154-11	Polybutylene Terephthalate (PBT)	50 mm	50 mm	Tubeaxial	0.033 A	3200 RPM	33.11 g	0.073 lb	70000 Hrs	15 mm	15.4 dB(A)	7.7 CFM	0.216 m³/min	Auto Restart Locked Rotor Sensor	0.07 in H2O	17.4 Pa	0.4 W	3 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	12 VDC	4.5 V	13.8 VDC
CUI Devices CFM-5015V-247-290-20	Polybutylene Terephthalate (PBT)	50 mm	50 mm	Tubeaxial	0.034 A	5000 RPM	37.65 g	0.083 lb	70000 Hrs	15 mm	29 dB(A)	13 CFM	0.364 mł/min	Auto Restart Speed Sensor (Tach)	0.17 in H2O	42.3 Pa	0.82 W	3 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	24 VDC
CUI Devices CFM-5015V-247-290	Polybutylene Terephthalate (PBT)	50 mm	50 mm	Tubeaxial	0.034 A	5000 RPM	37.65 g	0.083 lb	70000 Hrs	15 mm	29 dB(A)	13 CFM	0.364 mł/min	Auto Restart	0.17 in H2O	42.3 Pa	0.82 W	2 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	24 VDC
CUI Devices CFM-5015V-132-154-20	Polybutylene Terephthalate (PBT)	50 mm	50 mm	Tubeaxial	0.033 A	3200 RPM	33.11 g	0.073 lb	70000 Hrs	15 mm	15.4 dB(A)	7.7 CFM	0.216 m³/min	Auto Restart Speed Sensor (Tach)	0.07 in H2O	17.4 Pa	0.4 W	3 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	12 VDC	4.5 V	13.8 VDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 6.04
		10	$ 5.01
		25	$ 4.61
		50	$ 4.31
		200	$ 3.91

Description

General part information

CFM-5015 Series

Fan Tubeaxial 12VDC Square - 50mm L x 50mm H omniCOOL™ Magnetic Sleeve 10.2 CFM (0.286m³/min) 2 Wire Leads
