LPT92A99-BTHR

Active

Mechatronics Bearing Group

EC FAN AXIAL 92X92X38MM 120 TO 2

Search across all available documentation for this part.

Active

Mechatronics Bearing Group

EC FAN AXIAL 92X92X38MM 120 TO 2

Technical Specifications

Parameters and characteristics for this part

Specification	LPT92A99-BTHR

Air Flow	1.4 mł/min
Air Flow	50 CFM
Bearing Type	Ball
Current Rating (Amps) [Max]	0.08 A
Current Rating (Amps) [Min]	0.05 A
Fan Type	Tubeaxial
Features	Dual Voltage, Electronic Commutation (EC), Auto Restart
Material - Blade	Plastic
Material - Frame	Plastic
Noise	43 dB
Power (Watts)	4.8 W, 5.2 W
RPM	3850 RPM
Static Pressure	0.33 in H2O
Static Pressure	82.2 Pa
Termination	2 Terminals
Voltage - Rated [Max]	230 VAC
Voltage - Rated [Min]	115 VAC
Voltage Range [Max]	264 VAC
Voltage Range [Min]	95 VAC
Width [y]	38 mm

Part	Bearing Type	Air Flow	Air Flow	Static Pressure	Static Pressure	RPM	Voltage - Rated [Max]	Voltage - Rated [Min]	Voltage Range [Max]	Voltage Range [Min]	Material - Blade	Current Rating (Amps) [Max]	Current Rating (Amps) [Min]	Width [y]	Power (Watts)	Fan Type	Termination	Noise	Material - Frame	Features
Mechatronics Bearing Group LPT92A99-BTHR	Ball	1.4 mł/min	50 CFM	0.33 in H2O	82.2 Pa	3850 RPM	230 VAC	115 VAC	264 VAC	95 VAC	Plastic	0.08 A	0.05 A	38 mm	4.8 W 5.2 W	Tubeaxial	2 Terminals	43 dB	Plastic	Auto Restart Dual Voltage Electronic Commutation (EC)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fan Tubeaxial 115/230VAC Square - 92mm L x 92mm H Ball 50.0 CFM (1.40mł/min) 2 Terminals
