AC30
ActiveComus International
SSR RELAY SPST-NO 100MA 0-400V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AC30
ActiveComus International
SSR RELAY SPST-NO 100MA 0-400V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AC30 |
|---|---|
| Circuit | SPST-NO (1 Form A) x 2 |
| Load Current | 100 mA |
| Mounting Type | Through Hole |
| On-State Resistance (Max) [Max] | 30 Ohm |
| Output Type | DC, AC |
| Package / Case | 0.3 in |
| Package / Case | 8-DIP |
| Package / Case | 7.62 mm |
| Supplier Device Package | 8-DIP |
| Termination Style | PC Pin |
| Voltage - Input | 1.17 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 2.97 | |
| 1 | $ 4.35 | |||
| 10 | $ 2.65 | |||
| 10 | $ 3.80 | |||
| 25 | $ 3.60 | |||
| 45 | $ 2.45 | |||
| 50 | $ 3.46 | |||
| 90 | $ 2.37 | |||
| 100 | $ 3.32 | |||
| 135 | $ 2.32 | |||
| 250 | $ 3.15 | |||
| 270 | $ 2.24 | |||
| 500 | $ 3.02 | |||
| 540 | $ 2.17 | |||
| 1000 | $ 2.90 | |||
| 1035 | $ 2.10 | |||
| 5040 | $ 1.93 | |||
Description
General part information
- Series
Solid State SPST-NO (1 Form A) x 2 8-DIP (0.300", 7.62mm)
Documents
Technical documentation and resources
