S8VK-X03005-EIP

Active

Omron Electronics Inc-EMC Div

AC/DC DIN RAIL SUPPLY 5V 25W

Search across all available documentation for this part.

Active

Omron Electronics Inc-EMC Div

AC/DC DIN RAIL SUPPLY 5V 25W

Technical Specifications

Parameters and characteristics for this part

Specification	S8VK-X03005-EIP

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	ITE (Commercial)
Approval Agency	RCM, cURus, KC, EAC, UL, CE, TUV
Current - Output (Max) [Max]	5 A
DC Voltage - Input (Max) [Max]	350 V
DC Voltage - Input (Min) [Min]	90 V
Efficiency	78 %
Features	Adjustable Output, Universal Input, IP20
Input Type	AC or DC
Number of Outputs	1
Power (Watts)	25 W
Size / Dimension [x]	3.39 in
Size / Dimension [x]	86 mm
Size / Dimension [y]	40 mm
Size / Dimension [y]	1.57 "
Size / Dimension [z]	3.54 "
Size / Dimension [z]	90 mm
Voltage - Isolation	3000 V
Voltage - Output 1	5 V

Part	Applications	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Input Type	Current - Output (Max) [Max]	Voltage - Isolation	Features	DC Voltage - Input (Min) [Min]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Efficiency	Power (Watts)	Voltage - Output 1	Approval Agency	DC Voltage - Input (Max) [Max]	Number of Outputs
Omron Electronics Inc-EMC Div S8VK-X03005-EIP	ITE (Commercial)	85 VAC	264 VAC	AC or DC	5 A	3000 V	Adjustable Output IP20 Universal Input	90 V	3.54 "	3.39 in	40 mm	86 mm	1.57 "	90 mm	78 %	25 W	5 V	CE cURus EAC KC RCM TUV UL	350 V	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

AC/DC DIN RAIL SUPPLY 5V 25W
