OPB856Z

Active

TT Electronics/Optek Technology

SENSOR OPT SLOT PHOTOTRANS MODUL

Search across all available documentation for this part.

Active

TT Electronics/Optek Technology

SENSOR OPT SLOT PHOTOTRANS MODUL

Technical Specifications

Parameters and characteristics for this part

Specification	OPB856Z

Current - DC Forward (If) (Max) [Max]	40 mA
Mounting Type	M12 Threaded Body, Nut
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Output Configuration	Phototransistor
Package / Case	Module, Connector
Sensing Method	Through-Beam
Type	Unamplified
Voltage - Collector Emitter Breakdown (Max) [Max]	30 V

Part	Operating Temperature [Max]	Operating Temperature [Min]	Type	Current - DC Forward (If) (Max) [Max]	Mounting Type	Sensing Method	Output Configuration	Package / Case	Voltage - Collector Emitter Breakdown (Max) [Max]
TT Electronics/Optek Technology OPB856Z	85 °C	-40 °C	Unamplified	40 mA	M12 Threaded Body Nut	Through-Beam	Phototransistor	Connector Module	30 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Optical Sensor Through-Beam 12" (304.8mm) Phototransistor Module, Connector
