3292P-1-502

Active

Bourns Inc.

RES,CERMET,5KOHMS,400WVDC,10+/-% TOL,-100,100PPM-TC,3737-CASE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

3292P-1-502

Active

Bourns Inc.

RES,CERMET,5KOHMS,400WVDC,10+/-% TOL,-100,100PPM-TC,3737-CASE

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	3292P-1-502

Adjustment Type	Side Adjustment
Mounting Type	Through Hole
Number of Turns	25
Power (Watts)	0.5 W
Power (Watts)	0.5 W
Resistance	5 kOhms
Resistive Material	Cermet
Size / Dimension [x]	9.53 mm
Size / Dimension [x]	0.375 in
Size / Dimension [y]	3.81 mm
Size / Dimension [y]	0.15 in
Temperature Coefficient	100 ppm/°C
Termination Style	PC Pins
Tolerance	10 %

3292P Series

Part	Tolerance	Temperature Coefficient	Power (Watts)	Power (Watts)	Adjustment Type	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Number of Turns	Resistive Material	Mounting Type	Resistance	Termination Style
Bourns Inc. 3292P-1-202LF	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	2 kOhms	PC Pins
Bourns Inc. 3292P-1-502LF	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	5 kOhms	PC Pins
Bourns Inc. 3292P-1-502	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	5 kOhms	PC Pins
Bourns Inc. 3292P-1-103LF	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	10000 Ohms	PC Pins
Bourns Inc. 3292P-1-505LF	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	5 MOhms	PC Pins
Bourns Inc. 3292P-1-201LF	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	200 Ohms	PC Pins
Bourns Inc. 3292P-1-501LF	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	500 Ohms	PC Pins
Bourns Inc. 3292P-1-200	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	20 Ohms	PC Pins
Bourns Inc. 3292P-1-101LF	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	100 Ohms	PC Pins
Bourns Inc. 3292P-1-501	10 %	100 ppm/°C	0.5 W	0.5 W	Side Adjustment	3.81 mm	0.15 in	9.53 mm	0.375 in	25	Cermet	Through Hole	500 Ohms	PC Pins

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	100	$ 13.67
Newark	Each	100	$ 12.36
		250	$ 11.93
		500	$ 11.09

Description

General part information

3292P Series

5 kOhms 0.5W, 1/2W PC Pins Through Hole Trimmer Potentiometer Cermet 25.0 Turn Side Adjustment

Documents

Technical documentation and resources
