DS1250WP-100IND+

Obsolete

Analog Devices Inc./Maxim Integrated

IC NVSRAM 4MBIT PAR 34PWRCAP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

DS1250WP-100IND+

Obsolete

Analog Devices Inc./Maxim Integrated

IC NVSRAM 4MBIT PAR 34PWRCAP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	DS1250WP-100IND+

Access Time	100 ns
Memory Format	NVSRAM
Memory Interface	Parallel
Memory Organization	512 K
Memory Size	512 kb
Memory Type	Non-Volatile
Mounting Type	Surface Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	34-PowerCap™ Module
Supplier Device Package	34-PowerCap Module
Technology	NVSRAM (Non-Volatile SRAM)
Voltage - Supply [Max]	3.6 V
Voltage - Supply [Min]	3 V
Write Cycle Time - Word, Page [custom]	100 ns
Write Cycle Time - Word, Page [custom]	100 ns

DS1250W Series

Part	Mounting Type	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Memory Interface	Write Cycle Time - Word, Page [custom]	Write Cycle Time - Word, Page [custom]	Memory Size	Supplier Device Package	Memory Organization	Voltage - Supply [Max]	Voltage - Supply [Min]	Memory Format	Memory Type	Technology	Access Time	Package / Case	Package / Case	Write Cycle Time - Word, Page
Analog Devices Inc./Maxim Integrated DS1250WP-100IND+	Surface Mount	34-PowerCap™ Module	85 °C	-40 °C	Parallel	100 ns	100 ns	512 kb	34-PowerCap Module	512 K	3.6 V	3 V	NVSRAM	Non-Volatile	NVSRAM (Non-Volatile SRAM)	100 ns
Analog Devices Inc./Maxim Integrated DS1250W-100IND	Through Hole	32-DIP Module	85 °C	-40 °C	Parallel	100 ns	100 ns	512 kb	32-EDIP	512 K	3.6 V	3 V	NVSRAM	Non-Volatile	NVSRAM (Non-Volatile SRAM)	100 ns	0.6 in	15.24 mm
Analog Devices Inc./Maxim Integrated DS1250WP-150	Surface Mount	34-PowerCap™ Module	70 °C	0 °C	Parallel			512 kb	34-PowerCap Module	512 K	3.6 V	3 V	NVSRAM	Non-Volatile	NVSRAM (Non-Volatile SRAM)	150 ns			150 ns
Analog Devices Inc./Maxim Integrated DS1250WP-100+	Surface Mount	34-PowerCap™ Module	70 °C	0 °C	Parallel	100 ns	100 ns	512 kb	34-PowerCap Module	512 K	3.6 V	3 V	NVSRAM	Non-Volatile	NVSRAM (Non-Volatile SRAM)	100 ns
Analog Devices Inc./Maxim Integrated DS1250W-100IND+	Through Hole	32-DIP Module	85 °C	-40 °C	Parallel	100 ns	100 ns	512 kb	32-EDIP	512 K	3.6 V	3 V	NVSRAM	Non-Volatile	NVSRAM (Non-Volatile SRAM)	100 ns	0.6 in	15.24 mm
Analog Devices Inc./Maxim Integrated DS1250W-150+	Through Hole	32-DIP Module	70 °C	0 °C	Parallel			512 kb	32-EDIP	512 K	3.6 V	3 V	NVSRAM	Non-Volatile	NVSRAM (Non-Volatile SRAM)	150 ns	0.6 in	15.24 mm	150 ns

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

DS1250W Series

NVSRAM (Non-Volatile SRAM) Memory IC 4Mbit Parallel 100 ns 34-PowerCap Module
