VO3052-X007T

Active

Vishay General Semiconductor - Diodes Division

OPTOISOLATOR 5.3KV TRIAC 6SMD

Search across all available documentation for this part.

Active

Vishay General Semiconductor - Diodes Division

OPTOISOLATOR 5.3KV TRIAC 6SMD

Technical Specifications

Parameters and characteristics for this part

Specification	VO3052-X007T

Approval Agency	UR, cUR
Current - DC Forward (If) (Max) [Max]	60 mA
Current - Hold (Ih)	200 µA
Current - LED Trigger (Ift) (Max) [Max]	10 mA
Current - On State (It (RMS)) (Max)	100 mA
Mounting Type	Surface Mount
Number of Channels	1
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-55 °C
Output Type	Triac
Package / Case	6-SMD
Static dV/dt (Min) [Min]	1.5 kV/µs
Supplier Device Package	6-SMD
Voltage - Isolation	5300 Vrms
Voltage - Off State	600 V
Zero Crossing Circuit	False

Part	Current - On State (It (RMS)) (Max)	Voltage - Off State	Output Type	Number of Channels	Approval Agency	Current - LED Trigger (Ift) (Max) [Max]	Supplier Device Package	Current - DC Forward (If) (Max) [Max]	Package / Case	Package / Case	Package / Case	Static dV/dt (Min) [Min]	Current - Hold (Ih)	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Voltage - Isolation	Package / Case
Vishay General Semiconductor - Diodes Division VO3052-X016	100 mA	600 V	Triac	1	cUR UR VDE	10 mA	6-DIP	60 mA	6-DIP	10.16 mm	10.16 mm	1.5 kV/µs	200 µA	100 °C	-55 °C	Through Hole	5300 Vrms
Vishay General Semiconductor - Diodes Division VO3052-X007T	100 mA	600 V	Triac	1	cUR UR	10 mA	6-SMD	60 mA	6-SMD			1.5 kV/µs	200 µA	100 °C	-55 °C	Surface Mount	5300 Vrms
Vishay General Semiconductor - Diodes Division VO3053-X009T	100 mA	600 V	Triac	1	cUR UR	5 mA	6-SMD	60 mA	6-SMD Gull Wing			1.5 kV/µs	200 µA	100 °C	-55 °C	Surface Mount	5300 Vrms
Vishay General Semiconductor - Diodes Division VO3052	100 mA	600 V	Triac	1	cUR UR	10 mA	6-DIP	60 mA	6-DIP		7.62 mm	1.5 kV/µs	200 µA	100 °C	-55 °C	Through Hole	5300 Vrms	0.3 in
Vishay General Semiconductor - Diodes Division VO3053	100 mA	600 V	Triac	1	cUR UR	5 mA	6-DIP	60 mA	6-DIP		7.62 mm	1.5 kV/µs	200 µA	100 °C	-55 °C	Through Hole	5300 Vrms	0.3 in
Vishay General Semiconductor - Diodes Division VO3053-X006	100 mA	600 V	Triac	1	cUR UR	5 mA	6-DIP	60 mA	6-DIP	10.16 mm	10.16 mm	1.5 kV/µs	200 µA	100 °C	-55 °C	Through Hole	5300 Vrms

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Optoisolator Triac Output 5300Vrms 1 Channel 6-SMD
