B72280B0551K001

Active

EPCOS - TDK Electronics

VARISTOR 910V 100KA ENCASED DISC

Search across all available documentation for this part.

Active

EPCOS - TDK Electronics

VARISTOR 910V 100KA ENCASED DISC

Technical Specifications

Parameters and characteristics for this part

Part	Capacitance @ Frequency	Maximum AC Volts [Max]	Number of Circuits	Mounting Type	Package / Case	Maximum DC Volts [Max]	Varistor Voltage (Typ)	Energy	Current - Surge	Varistor Voltage (Max) [Max]	Varistor Voltage (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Varistor Voltage (Max)
EPCOS - TDK Electronics B72280B0441K001	8100 pF	440 V	1	Chassis Mount	Encased Disc	585 V	715 V	2350 J	100 kA	786.5 V	643.5 V	85 °C	-40 °C
EPCOS - TDK Electronics B72280B0461K001		460 V	1	Chassis Mount	Encased Disc	615 V	750 V	2500 J	100 kA	825 V	675 V	85 °C	-40 °C
EPCOS - TDK Electronics B72280B0551K001	6500 pF	550 V	1	Chassis Mount	Encased Disc	745 V	910 V	3100 J	100 kA	1.001 kV	819 V	85 °C	-40 °C
EPCOS - TDK Electronics B72280B0131K001	28000 pF	130 V	1	Chassis Mount	Encased Disc	170 V	205 V	660 J	100 kA		184.5 V	85 °C	-40 °C	225.5 V
EPCOS - TDK Electronics B72280B0231K001	16000 pF	230 V	1	Chassis Mount	Encased Disc	300 V	360 V	1200 J	100 kA	396 V	324 V	85 °C	-40 °C
EPCOS - TDK Electronics B72280B0421K001	8500 pF	420 V	1	Chassis Mount	Encased Disc	560 V	680 V	2200 J	100 kA	748 V	612 V	85 °C	-40 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

910 V 100 kA Varistor 1 Circuit Chassis Mount Encased Disc
