PFSM.030.2

Active

SCHURTER Inc.

PFSM, IHOLD 0.3 A, 60.0 VDC, RESETTABLE FUSE, PCB ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

SCHURTER Inc.

PFSM, IHOLD 0.3 A, 60.0 VDC, RESETTABLE FUSE, PCB ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	PFSM.030.2

Approval Agency	cURus, TUV
Current - Hold (Ih) (Max) [Max]	300 mA
Current - Max [Max]	40 A
Current - Trip (It)	600 mA
Grade	Automotive
Mounting Type	Surface Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	2-SMD
Qualification	AEC-Q200
Resistance - Initial (Ri) (Min) [Min]	900 mOhms
Resistance - Post Trip (R1) (Max) [Max]	4.8 Ohms
Thickness (Max) [Max]	3.18 mm
Thickness (Max) [Max]	0.125 in
Time to Trip	3 s
Type	Polymeric
Voltage - Max [Max]	60 V

Part	Approval Agency	Grade	Thickness (Max) [Max]	Thickness (Max) [Max]	Package / Case	Type	Qualification	Operating Temperature [Max]	Operating Temperature [Min]	Current - Hold (Ih) (Max) [Max]	Current - Max [Max]	Voltage - Max [Max]	Time to Trip	Resistance - Post Trip (R1) (Max) [Max]	Resistance - Initial (Ri) (Min) [Min]	Current - Trip (It)	Mounting Type
SCHURTER Inc. PFSM.030.2	cURus TUV	Automotive	3.18 mm	0.125 in	2-SMD	Polymeric	AEC-Q200	85 °C	-40 °C	300 mA	40 A	60 V	3 s	4.8 Ohms	900 mOhms	600 mA	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Polymeric PTC Resettable Fuse 60V 300 mA Ih Surface Mount 2-SMD
