CMD-HHCP-315-MD

Active

TE Connectivity Linx

XMITTER HANDHELD 315MHZ 8 BUTTON

Search across all available documentation for this part.

Active

TE Connectivity Linx

XMITTER HANDHELD 315MHZ 8 BUTTON

Technical Specifications

Parameters and characteristics for this part

Specification	CMD-HHCP-315-MD

Applications	Garage Opener, General Remote Control, RKE
Features	750 ft.
Features	8 Buttons
Frequency	315 MHz
Function	Transmitter
Interface	8 Button, Handheld
Modulation or Protocol	ASK, OOK
Voltage - Supply [Max]	3.6 V
Voltage - Supply [Min]	2.1 V

Part	Function	Voltage - Supply [Min]	Voltage - Supply [Max]	Modulation or Protocol	Features	Features	Interface	Frequency	Applications	Data Rate (Max)
TE Connectivity Linx CMD-HHCP-315-MD	Transmitter	2.1 V	3.6 V	ASK OOK	750 ft.	8 Buttons	8 Button Handheld	315 MHz	Garage Opener General Remote Control RKE
TE Connectivity Linx CMD-HHCP-418-MD	Transmitter	2.1 V	3.6 V	ASK OOK	750 ft.	8 Buttons	8 Button Handheld	418 MHz	Garage Opener General Remote Control RKE
TE Connectivity Linx CMD-HHCP-315	Transmitter	2.1 V	3.6 V	ASK OOK	8 RU 1000 ft.		8 Button Handheld	315 MHz	Garage Opener General Remote Control RKE	1.2 kbps

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	20	$ 53.75

General part information

RF Transmitter 315MHz ASK, OOK Handheld, 8 Button
