Q-680520003001M

Active

Amphenol Custom Cable

COAX CBL RP-SMA TO TNC 3.3'

Search across all available documentation for this part.

Active

Amphenol Custom Cable

COAX CBL RP-SMA TO TNC 3.3'

Technical Specifications

Parameters and characteristics for this part

Part	2nd Connector	Length	Length	Length	Color	Features	Frequency - Max [Max]	1st Connector Mounting Type	Style	Connector Impedance	Overall Impedance	1st Connector	2nd Contact Gender	2nd Connector Mounting Type	Cable Impedance	1st Contact Gender	Cable Type
Amphenol Custom Cable Q-680520003001M	TNC Plug	1 m	3.3 ft	39.4 in	Black	Shielded	1 GHz	Free Hanging (In-Line)	RP-SMA to TNC	50 Ohms	50 Ohms	RP-SMA Plug	Male	Free Hanging (In-Line)	50 Ohms	Female	RG-174
Amphenol Custom Cable Q-680520005006I	TNC Plug	152.4 mm		6 in	Copper	Shielded	3 GHz	Free Hanging (In-Line)	RP-SMA to TNC	50 Ohms	50 Ohms	RP-SMA Plug	Male	Free Hanging (In-Line)	50 Ohms	Female	RG-316

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Assembly Coaxial RP-SMA to TNC RG-174 39.4" (1.0m) 3.3'
