Specification	XR77103EVB-DEMO-1

Board Type	Fully Populated
Main Purpose	DC/DC, Step Down
Outputs and Type	Non-Isolated
Outputs and Type	3
Regulator Topology	Buck
Supplied Contents	Board(s)
Utilized IC / Part	XR77103
Voltage - Output [Max]	6 VDC
Voltage - Output [Min]	0.8 V

XR77103 Series

Part	Regulator Topology	Board Type	Main Purpose	Outputs and Type	Outputs and Type	Voltage - Output [Min]	Voltage - Output [Max]	Supplied Contents	Utilized IC / Part	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input (Max) [Max]	Function	Supplier Device Package	Output Type	Voltage - Output (Min/Fixed)	Voltage - Output (Min/Fixed)	Voltage - Output (Min/Fixed)	Voltage - Output (Min/Fixed)	Current - Output	Number of Outputs	Package / Case	Voltage - Output (Max) [Max]	Output Configuration	Frequency - Switching	Topology	Voltage - Input (Min) [Min]	Mounting Type	Frequency - Switching [Min]	Frequency - Switching [Max]
MaxLinear, Inc. XR77103EVB-DEMO-1	Buck	Fully Populated	DC/DC Step Down	Non-Isolated	3	0.8 V	6 VDC	Board(s)	XR77103
MaxLinear, Inc. XR77103ELB-A0R5										-40 °C	125 ¯C	14 V	Step-Down	32-TQFN (4x4)	Adjustable (Fixed)	0.8 V	9 V	12 V	5 V	2 A	3	32-VFQFN Exposed Pad	13.3 V	Positive	500 kHz	Buck	4.5 V	Surface Mount
MaxLinear, Inc. XR77103ELB-A1R0										-40 °C	125 ¯C	14 V	Step-Down	32-TQFN (4x4)	Adjustable (Fixed)	0.8 V	9 V	12 V	5 V	2 A	3	32-VFQFN Exposed Pad	13.3 V	Positive	1 MHz	Buck	4.5 V	Surface Mount
MaxLinear, Inc. XR77103ELBTR										-40 °C	125 ¯C	14 V	Step-Down	32-TQFN (4x4)	Adjustable	0.8 V				2 A	3	32-VFQFN Exposed Pad		Positive		Buck	4.5 V	Surface Mount	300 kHz	2.2 MHz
MaxLinear, Inc. XR77103ELBTR-A1R0										-40 °C	125 ¯C	14 V	Step-Down	32-TQFN (4x4)	Adjustable (Fixed)	0.8 V	9 V	12 V	5 V	2 A	3	32-VFQFN Exposed Pad	13.3 V	Positive	1 MHz	Buck	4.5 V	Surface Mount
MaxLinear, Inc. XR77103ELBTR-A0R5										-40 °C	125 ¯C	14 V	Step-Down	32-TQFN (4x4)	Adjustable (Fixed)	0.8 V	9 V	12 V	5 V	2 A	3	32-VFQFN Exposed Pad	13.3 V	Positive	500 kHz	Buck	4.5 V	Surface Mount
MaxLinear, Inc. XR77103EVB-A1R0	Buck	Fully Populated	DC/DC Step Down	Non-Isolated	3	0.8 V	6 VDC	Board(s)	XR77103-A1R0											2 A					1 MHz

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	2	$ 63.13

Description

General part information

XR77103 Series

XR77103 - DC/DC, Step Down 3, Non-Isolated Outputs Evaluation Board
