L313F

Obsolete

Sensata-Crydom

L SERIES POWER MODULE

Search across all available documentation for this part.

Obsolete

Sensata-Crydom

L SERIES POWER MODULE

Technical Specifications

Parameters and characteristics for this part

Specification	L313F

Current - Gate Trigger (Igt) (Max) [Max] [x]	100 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	2250 A
Mounting Type	Chassis Mount
Number of SCRs, Diodes [custom]	2
Number of SCRs, Diodes [custom]	2
Operating Temperature [Max]	125 ¯C
Operating Temperature [Min]	-40 °C
Package / Case	Module
Structure	Bridge, Single Phase - SCRs/Diodes (Layout 1)
Voltage - Gate Trigger (Vgt) (Max)	2.5 V
Voltage - Off State	800 V

Part	Number of SCRs, Diodes [custom]	Number of SCRs, Diodes [custom]	Current - Non Rep. Surge 50, 60Hz (Itsm)	Voltage - Gate Trigger (Vgt) (Max)	Structure	Current - Gate Trigger (Igt) (Max) [Max] [x]	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Voltage - Off State
Sensata-Crydom L313F	2	2	2250 A	2.5 V	Bridge Single Phase - SCRs/Diodes (Layout 1)	100 mA	Chassis Mount	-40 °C	125 ¯C	Module	800 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

SCR Module 800 V Bridge, Single Phase - SCRs/Diodes (Layout 1) Chassis Mount Module
