RR3402A

Active

E-Switch

SWITCH ROCKER SPST 6A 125V

Search across all available documentation for this part.

Active

E-Switch

SWITCH ROCKER SPST 6A 125V

Technical Specifications

Parameters and characteristics for this part

Specification	RR3402A

Actuator Marking	No Marking
Actuator Type	Paddle
Circuit	SPST
Color - Actuator/Cap	Black
Current Rating (Amps)	6 A
Electrical Life	6000 Cycles
Mechanical Life	20000 Cycles
Mounting Type	Panel Mount, Threaded Body with Nut
Operating Temperature [Max]	65 °C
Operating Temperature [Min]	0 °C
Panel Cutout Dimensions [diameter]	15 mm
Switch Function	On-Off
Termination Style	Solder Lug
Voltage Rating - AC	125 V

Part	Current Rating (Amps)	Termination Style	Panel Cutout Dimensions [diameter]	Switch Function	Actuator Type	Color - Actuator/Cap	Actuator Marking	Mounting Type	Voltage Rating - AC	Circuit	Mechanical Life	Electrical Life	Operating Temperature [Max]	Operating Temperature [Min]
E-Switch RR3405A	10 A	Solder Lug	18 mm	On-Off	Paddle	Black	No Marking	Panel Mount Threaded Body with Nut	125 V	DPST
E-Switch RR3402A	6 A	Solder Lug	15 mm	On-Off	Paddle	Black	No Marking	Panel Mount Threaded Body with Nut	125 V	SPST	20000 Cycles	6000 Cycles	65 °C	0 °C
E-Switch RR3402C	6 A	Solder Lug	15 mm	On-On	Paddle	Black	No Marking	Panel Mount Threaded Body with Nut	125 V	SPDT	20000 Cycles	6000 Cycles	65 °C	0 °C
E-Switch RR3402D	6 A	Solder Lug	15 mm	On-Off-On	Paddle	Black	No Marking	Panel Mount Threaded Body with Nut	125 V	SPDT	20000 Cycles	6000 Cycles	65 °C	0 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Rocker Switch SPST 6A (AC) 125 V Panel Mount, Threaded Body with Nut

Technical documentation and resources

No documents available
